Special Acid-proof Brick
Lightweight acid-proof Brick
Acid resistant brick is the ideal choose for your project with their features of proof pressure, corrosion resistance, easy to clean and acid-base resistance.
Acid-resistant bricks for coke ovens
Product features:
Acid-resistant bricks have the properties of anti-permeability ,anti-freezing, salt resistance,alkali resistance and week acid corrosion,and have strong adhesion to a variety of materials, it can be constructed on the surface of damp substrate without drying.It can be hardened in humid environment or under water. Easy operation and construction,similar to ordinary cement mortar construction ,easy cleaning ,water can be cleaned .In industry, it is mainly used in acid ditch. acid well ,acid storage and-loaded ground.
index |
Special acid-resistant brick |
Lightweight acid-resistant brick |
SiO2%≥ |
65 |
65 |
Bulk density g/cm3 BD |
1.6-1.8 |
1.0-1.3 |
Compressive strength CCS Mpa≥ |
15 |
10 |
Thermal Conductivity w/m.k (350℃±25℃)≤ |
0.65 |
0.45 |
water absorption%WR≤ |
15 |
|
Acid resistance%APR≥ |
98 |
97 |
long-term operating temperature℃HR< |
1000 |
950 |
characteristic |
Good acid resistance, small volume change, and significant corrosion resistance and corrosion resistance |
|
Application area |
flue, chimney lining, etc. |
Silica brick is an acidic refractory mainly composed of tridymite, cristobalite and a small amount of residual quartz and glass phases
Silica brick: an acidic refractory mainly composed of tridymite, cristobalite and a small amount of residual quartz and glass phases. Its silica content is more than 94%, it has anti-acid slag erosion performance, high high temperature strength, high load softening temperature, long-term use in high temperature flower wells without deformation, but low thermal shock stability (heat exchange in water is 1-4 Second-rate).
Silica bricks for coke ovens are siliceous refractory products used for building coke ovens with tridymite as the main crystal phase. Coke oven silica bricks are used to build regenerator walls, ramps, combustion chambers, carbonization chambers and furnace roofs of coke ovens. Silica brick is an acid refractory material with good resistance to acid slag erosion. The softening temperature under load is as high as 1640-1670 °C, and the volume is relatively stable in long-term use at high temperature.
Coke furnace silicon bricks are mainly used in the heat storage room, oblique road, charcoal room, combustion room, top of the furnace, and bottom of the furnace.
High alumina refractory mortars used in kilns in metallurgy, building materials, machinery, chemical industry, electric power and other industries, used for masonry clay bricks, high alumina bricks, corundum bricks, with full ash joints, good air tightness of masonry, high bonding strength, high temperature performance Excellent, suitable for construction time and so on.
High alumina refractory bricks are the backbone of high-temperature industrial processes. By understanding their properties, applications, and supplier selection criteria, businesses can enhance operational efficiency and reduce downtime. For industries seeking durable, cost-effective solutions, partnering with certified refractory materials suppliers in China ensures access to cutting-edge technology and reliable supply chains.
The Al2O3 content of clay heat Clay insulating refractory bricks is generally more than 40%, and the Fe2O3 content is less than 2.0-2.5%. The clinker in the ingredients is 65-85%, and the combined clay is 35-15%. The crushed bonded clay and the finely ground clinker are mixed and milled, and then mixed with the granular clinker to make semi-dry mud, high pressure molding, and sintering at about 1400 ℃, with good performance.
The refractory ramming material is prepared from a high proportion of granular and powdery materials and a very low proportion of binders and other components, even all of which are composed of granules and powders, and are subject to strong ramming. Bulk materials for construction.
